5X ALFA Integrated Seed Cleaning and Grading Machine
The Agrotech Ars-5XALFA Integrated Seed Cleaning and Grading Machine is a high-capacity, mobile agricultural processing system designed to combine multiple seed and grain cleaning, separation and grading operations in one machine.
It is suitable for large agricultural farms, seed companies and processing facilities handling sesame, maize, paddy rice, mung beans, melon seeds, wheat and other compatible agricultural products.
Operating Principle
The cleaning process begins with a bucket elevator designed to reduce grain breakage during material transfer.
Incoming products undergo pre-cleaning followed by dual air separation stages that help remove lightweight impurities and foreign materials.
The material then passes through dual gravity separation stages, supporting separation according to differences in grain density and physical characteristics.
Vibrating sieves perform further cleaning and grading by separating materials of different sizes. Rubber balls moving through vibration help keep the sieve surfaces clean during operation.
Electromagnetic Gravity Table Control
The machine incorporates an electromagnetic frequency adjustment system for the gravity separation table.
This allows operating conditions to be adjusted according to the properties of different seeds and grains, supporting controlled separation.
Sieve Cleaning System
The vibrating sieves are equipped with a rubber-ball cleaning mechanism that helps remove material trapped in the screen openings.
This system supports consistent sieve operation throughout the cleaning and grading process.
Cyclone Dust Removal
An integrated cyclone dust removal system collects dust generated during product cleaning.
It helps limit dust dispersion and provides cleaner processing conditions.
Mobile Operation
The machine features a vehicle-towable mobile structure that supports transportation between farms, processing locations and agricultural work sites.
This makes it suitable for operations requiring mobility and flexible equipment deployment.
Key Features and Advantages
- Integrated Multi-Stage Processing: Combines pre-cleaning, air separation, gravity separation, vibrating sieving and grading.
- High Cleaning Rate: At least 97%.
- Processing Capacity: 7/5 tons per hour based on wheat.
- Grain-Friendly Bucket Elevator: Designed to reduce breakage during product handling.
- Dual Air Separation: Helps remove lightweight impurities.
- Dual Gravity Separation: Supports separation according to grain density.
- Vibrating Screening System: Cleans and grades agricultural products.
- Rubber-Ball Sieve Cleaning: Helps maintain clear screen openings.
- Electromagnetic Frequency Adjustment: Enables gravity table operating adjustments.
- Cyclone Dust Removal: Collects dust during processing.
- Vehicle-Towable Design: Supports mobile agricultural operations.
- Three-Phase Electrical Supply: Total power of 16.1 kW.
- Noise Level: Below 85 dB.
Suitable Products
- Sesame
- Maize
- Paddy rice
- Mung beans
- Melon seeds
- Wheat
- Other compatible seeds and grains
Applications
- Seed cleaning and grading plants
- Large-scale agricultural farms
- Grain processing and preparation facilities
- Pulse processing centers
- Mobile agricultural cleaning operations
- Agricultural seed preparation systems
Technical Overview
Model: Ars-5XALFA
Dimensions: 3600 × 2200 × 6470 mm
Processing Capacity: 7/5 tons/hour
Cleaning Rate: ≥97%
Total Electrical Power: 16.1 kW
Electrical Input: Three-phase
Noise Level: Below 85 dB
Agrotech provides integrated seed cleaning, separation and grading machinery solutions designed to support efficient agricultural processing operations.
